AlixLabs AB
Country of Citizenship:
SWEDENProduct / Solution:
Next-Gen Semiconductor Manufacturing: Breaking optical limits to enable sub-20nm chip structures at lower cost.highlight
APS —— 推動半導體微縮的顛覆性永續技術，降低成本、能耗、碳排與用水。
APS, a disruptive and sustainable method for advancing semiconductor scaling — reducing cost, energy consumption, CO₂ emissions, and water usage.
company description
AlixLabs 的 APS 技術提供一種顛覆性且永續的方法，加速半導體微縮發展。透過原子級精準製程，APS 可在無需昂貴次世代微影的情況下，實現次10奈米結構。此技術完全相容現有設備，能有效降低資本與營運成本、減少能源與水資源消耗，並降低二氧化碳排放。這項突破讓晶圓廠能在提升效能與密度的同時，邁向更綠色、更高效的製造未來。
AlixLabs’ APS technology offers a disruptive, sustainable method for advancing semiconductor scaling. APS enables sub-10nm features via atomic-precision processes, without costly next-gen lithography. Fully compatible with existing tools, APS reduces Capex and Opex, lowers energy and water use, and cuts CO₂ emissions. This breakthrough allows Fabs to push performance and density limits while advancing toward greener, more efficient manufactering.
